Before makeups and new cells...ComponentsLeft sideand from another anglea close up on mtor settiming holes
LocationSouthern Finland Finland map
Web/EmailWebPage email image
Vehicle1997 Suzuki 1000 RR
Was quite scary device before. And I try make it even more scarier..
MotorAdvanced DC 6,7" K91-4003, timing advanced Series Wound DC
Two paralled, no paraller/series contactors
DrivetrainSingle gear ratio 1:4,25 with two paralled 6,7" ADCs and 1k Zilla
ControllerCafe Electric 1k Zilla LV
Nothing to add. Sooo Nize piece of equipment...
Batteries48 LiFePO4 1s10p 25 Ah, 3.20 Volt, Lithium-Ion
Tested with LCP-200, LMP-30, LFP-30 and LCP-50. Now K2 cells go in ...
System Voltage153 Volts
ChargerFEVT PAC1000
onboard charger and controlled with CCS.
HeaterWarm Finnish summer weather..
DC/DC ConverterMeanwell 230VAC -12VDC
Normal AC-DC which seems to eat DC very nicely. two seperate powersupplies for electronics and for aux devices (lights etc.)
InstrumentationCCS interface (7" TFT touch screen) and Vapor speedometer. Screen has 2 video inputs :) Might go for rearview camera
Top Speed150 MPH (241 KPH)
Target. Untested yet. Calculated up to 190 km/h but in the end it depends now on the battery output performance.
AccelerationWe had some test runs and it took less than 100 meters to get the speed to scary-zone. Calculation came out with 2,7s to 100 km/h.
Range60 Miles (96 Kilometers)
Estimated, TBD. If cruising with 80 km/h I should have this range. On highway I bet it's less than half of that.
Watt Hours/Mile66 Wh/Mile
Estimated, TBD
EV Miles
Current:10 Miles (16 Kilometers)
Seating Capacity1 adult
Curb Weight500 Pounds (227 Kilograms)
So far it looks lie I'm going to be able to keep the target weight. I'll scale it when setup is ready.
Conversion Timeall my freetime. Which is not that much.
Conversion Cost10 000 eur.. and counting...
Additional FeaturesIt will kill....
Currently going through it completely. Renewed cooling system and wiring. Now after getting the battery setup right have to get new covers. Have to add some sort of cNeed to build better enclosure for Zilla. Noticed some water spray on it after test runs. New cables are 70 mm^2 at motor side.
