side view 2rear wheel3600 lumens of LED88.8V 15Ah lipo ( 20C)rear manitou shock
OwnerDoctorbass
Owner's Other EVs1996 Trek 970
2008 Mongoose
2008 Supercycle Hooligan
WORLD FASTEST ELECTRIC BICYCLE june 2009
2011 KMX Typhoon
2014 / 1991 Sears Craftman 825 Track Drive
LocationQuebec, Quebec Canada map
Web/EmailWebPage email image
Vehicle2003 GIANT DH comp
-Bearing and bushings are brand new.
-8 inchs rear using Manitou six way and
7 inchs boxxer on the front
-Shimano xt Dehore 4 pistons brake,
-Sun Rim double track using marzocchi
for front wheel.
-Recommanded for a person of 5'10" or
more
MotorCrystalyte 5303-5306 DIY serie parallel relay Brushless DC
This motor is rated 750W nominal but we
are few people to push them to take up to
20kW if monitoring temp
DrivetrainCrystalyte X5 powerfull hub motor!!
ControllerKelly KBL 220A 120V
Programmable Brushless controller
( can take up to 136VDC)
Batteries15 zippy flightmax 6s 5000mAh 20C and 30C, 111.00 Volt, Lithium-Polymer
These battery come from hobbycity.com and
are usually made for RC toy.

I have total of 1.6kWh energy
System Voltage111 Volts
Charger Meanwell RSP-1500-48
it's a power supply that I'm using in
power limiting conditions for the CC-CV.
It push 1700Watts DC continuous and can be
connected to a normal 120V ac outlet. It
take 45 minutes for full charge
DC/DC Converter 12V 5A switching power supply used as DC-DC
It cost just 9.99$ and can supply
everything on the ebike that need 12V like
the 4x 900 lumens Magicshine LED...
InstrumentationLarge screen Cycle Analyst v2.23
Top Speed70 MPH (112 KPH)
It's the max speed I acheived with it from
now but I was limited by the street length
=( and I needed to apply the brake to not
crash in the border!
Accelerationpretty well and surprizing!!! the 40 to 80
kph is very fast!!
Range35 Miles (56 Kilometers)
1600Wh energy at 20Wh per km at 32kmh is
around 40 miles (no pedal) on pavement
Watt Hours/Mile30 Wh/Mile
This ebike is not made for RANGE.. but
more for INTENSE FUN !!!
EV Miles
Current:698 Miles (1,123 Kilometers)
Seating Capacity1
Curb Weight98 Pounds (44 Kilograms)
TiresArrow Racing Wide bite 24 x 3.0" tires and
DH tube
Conversion Time1 month
Conversion Cost4500$
Additional FeaturesThe hanlding is very great and impressive!!! eventhough it co
to 113km/h, it feel confortable
This became my fastest electric bike i ever made.

Follow me on Twitter: DocbassMelancon


Certainly the best DH ebike in the world for the
performances!!!

Can go up hill.. ity have all the torque to climb
everything!

No more need mountain to get the same fun as conventional
DH
bike!!! You can now to what you want on flat!!!

Certainly the best built I've done from now!!!



Doc
